Enjoying hobby flight is a changing beast these days and drones typically add a new layer to it all. The machines of old took to the sky without a camera, or they hauled a GoPro to capture footage to watch later. The modern drone packs a camera, sometimes a really good camera, but does more than just capture footage for later viewing.
Live streaming video from the sky is a great way to experience drone flight. Putting that video in front of your eyes can be done in a number of ways, today we’ll look at the three most popular as we discuss the pros and cons of each. If you need a teaser, FPV is very helpful for orienting yourself in the sky with a camera drone, and all but required if you’re racing around a track, but a little screen on your remote might be enough for a basic flight.
Why trust Drone Rush?
I’ve been a fan of flight since a young age; while I’ve had few opportunities at the helm of manned aircraft, the hours on my fleet of drones continue to grow. I enjoy putting cameras into the sky, silky smooth aerial imagery makes me happy. My goal is to help all pilots enjoy flight legally and safely.
Legal and safety
Most places in the world enforce line-of-sight rules for flight. It is really as simple as it sounds, you must be able to see your drone by eye at all times during flight. If you put your head into FPV goggles, you’ve officially taken your eyes off of your drone.
In the United States, the FAA requires that pilot in FPV have a dedicated Visual Observer for these flights. That person must be able to see the drone at all times, and be within verbal communication range of the pilot. (This is for outdoor flight, which is why a lot of drone races are indoors, where there are no laws to follow.)
Otherwise, all drone laws still apply.
We forgot to mention that some drones handle live stream video differently. In the majority of cases, one camera shares the task of recording and sending the video over live to your display. There are other drones, however, that split the task. We are mostly thinking of the DJI Inspire 2 and DJI Matrice 200 series drones.
On these machines, there is a dedicated simple camera for the pilot, this video stream is still high quality, but is not fully stabilized or loaded with features.
These drones are intended to fly with two pilots. One controls the drone itself, the other operates the camera. Having said that, the main cameras for these drones are a collection of impressive shooters. Either way, there’s a video stream coming your way from the drones, how should you receive it?
Special note: racing drones We are going to dive into this list discussing modern and mostly proprietary devices and protocols. Any of you that have flown racing drones likely already know that your typical analog signal on a channel in the 5.8GHz range is different than what we'll look at today. We will expand on this at a later date, but for now, for the most part, the mobile devices, headsets, and external displays we're looking at below are not the tools you need to race. Look near the end of this article for one diversity receiver monitor that we like, at least.
The video streaming options
It is entirely likely that if you’ve flown a drone, you used a mobile device either as the controller or as the video streaming screen along with the controller. This is, by far, the most common method to enjoy live drone video.
Some remotes have built-in displays. These types of displays can often be purchased on their own, allowing you to use them in place of a mobile device or mount them somewhere for others to watch along as you fly. These are not, however, very common.
Finally, there are goggles. Either AR or VR, like the Epson Moverio smart glasses or the DJI Goggles. Racers will live inside of their Fat Shark headsets. Also, many brands offer their own headset that does not have a display, for these you use your mobile device as the display, but we’ll just pretend that that’s not the case for the sake of our arguments today.
Let’s dive in.
Mobile device drone display
The most common video streaming display, as you know, is your mobile device. This can be a phone or a tablet and most Android and iOS machines are supported for most drones.
Convenience is the name of the game. You are likely already hauling around a mobile phone, why not put it to use? That said, most mobile devices have very high screen resolution these days, which means that the display can keep up with almost all current video streaming resolutions.
What we like
- Lower cost to buy the drone
- Very portable
What we don’t like
- Your mobile device is tied up
- Video streaming uses a lot of battery
- Usually a small display
- Requires apps on your phone
- Sits in your hand
- Can be unreliable
There is a reason that mobile devices are the most common drone video streaming display. They are convenient and offer you the most flexibility as to the size of display you want to use. However, they are a sort of lazy way to do things.
I’m not implying that building and maintaining a reliable mobile app is easy, or cheap, but by not providing a display with the drone remote, a manufacturer saves a lot of money.
My biggest gripe with using a mobile device as a drone display is the varying functions and quality. Specifically, I am an Android user at heart, but, the iOS app provided by many companies works better on the iPad than the companion app on any of my Android machines. (The funny thing here is that most controllers with built-in display are powered by Android.)
When a manufacturer provides both drone and display, there is usually a lot more cohesion. The result is far fewer hiccups that are ultimately out of the manufacturers’ control. Having crashed a drone because the video on my mobile device had frozen, well, I’m not over that yet.
My little crash (no harm done, by the way,) was a result of the last con for this video method. It’s pretty simple, your drone is in the sky above you, your mobile device and the remote control are in your hands below eye level. You either look at your drone or at your phone. Or hold your arms in the air awkwardly.
I certainly wish all of my drones had displays built into the remote, but mobile devices are here to stay.
If you need a new Android phone or tablet, be sure to visit our partner site Android Authority.
Built-in drone display
I imagine I do not need to say much here, a display built into a remote control offers little flexibility, but offers no mystery either. Some of these setups will have the display permanently embedded, but some do have mounts on which you can put different panels.
What we like
- Always ready to go
What we don’t like
- Usually a one-size fits all small display
- Consumes remote control battery
- Limited resolution
- Sometimes black and white panels
Reliability is the name of the game here. Having a display built into your remote control is very convenient, for sure, but offers the most tailored experience a manufacturer can offer. Specifically, connectivity is usually far more reliable than with a mobile device.
With a mobile device, you could utilize long cables to put the display up higher or mount it to the side. With a display embedded in the remote, that’s where it lives for good.
Aside from the more expensive options out there, we’ve also only ever experienced very low resolution displays, with poor color quality. Don’t get me wrong, for FPV flying, lower resolution and lack of color is not often an issue.
The biggest concern with built-in displays is the battery consumption. When you use a phone as the display, if the phone dies, you simply fly the drone home, or keep going if you wish. When the embedded display on your remote runs out of juice, well, you best hope your drone has an automated RTH feature. There are safeguards on may, that turn off the display with enough battery to still fly, but not all, be careful out there.
As mentioned, however, not all of these displays are embedded in the remote. In fact, you can purchase a third-party display that can connect to your drone. In this regard you could mount the display to your remote, or as you’ll see at a production video shoot, the monitor will sit to the side for others to view. These types of displays do not sap remote battery, do not distract the pilot and are usually pretty reliable of a connection, the trade-off is price.
FPV goggles – AR or VR drone video headsets
As mentioned, FPV goggles can come in the form of Augmented Reality glasses or as fully enclosed VR headsets. For our purposes today, we will treat them as the same thing, but you should know that they are not. Not really.
The primary difference, and it’s pretty big, AR glasses do not typically break your line of sight to the drone, so you can wear them and fly. VR goggles are designed to fully enclose, breaking your line of sight to the drone. We’ll explore this difference in detail at another time. For today, both options put the display right in front of your face!
What we like
- Great visibility
- Always within your line of sight
What we don’t like
- Can cause nausea
- Most people can only wear for a few minutes at a time
- Completely blind if anything goes wrong
- Require a spotter to fly outdoors
The purpose of FPV goggles is really to put you in the seat of the drone. If you’ve never experienced it, I highly recommend giving it a try. Instead of watching your drone from afar, you get to see the world zip by from the nose of your craft. In many ways, it’s like playing a video game, except there is a real world object out there that needs you to do more than hit the retry button if you crash.
Requiring a co-pilot to fly outdoors is a huge inconvenience, but usually worth it. The view from the drone is critical for things like racing, making it much easier to remember which way is left when you get spun around. However, when you crash, depending on your orientation, there is no way to tell if you are right side up or what direction you are facing. Getting in and out of FPV goggles mid-flight is not entirely as simple as it sounds.
VR goggles in themselves cause a little wooziness for many. Once again, removing the goggles mid-flight can be dangerous. Stopping to faint, fall over or to get sick are, essentially, in violation of FAA flight rules. It’s your job to see a flight through to a safe landing.
With all the cons, the pros are really pretty fantastic. As I say, I hope you all get to experience drone flight video through VR goggles.
We enjoy the DJI Goggles around here. Truth is, I usually do not have a spotter along, so I fly my route, capture the video then transfer it into the Goggles for later viewing. In this way I can also share the experience with friends and family knowing that the drone is safely on the ground as the video plays. I might also mention that the last family gathering I had like this was over an hour long. The DJI Goggles last upwards of 6 hours on a charge, the Mavic Pro does not.
In the case of the DJI Goggles, the display is equivalent to a 216 inch TV sitting about 10 feet from you. You can do the math or imagine what that looks like, but I’ll just say, it’s huge. The display effectively covers your entire visual range. That is a pro and a con in itself – it’s amazingly immersive, but looking from corner to corner definitely pushes the eye muscles to make happen.
Finally, in the cons section is the issue of latency. Particularly important for racers, if the video on your display is half a second or more delayed behind what is actually going on with your drone, you probably already crashed. The better the video quality, the slower it is to transmit. The DJI Goggles have a really nice display, but they are too slow to race in the big leagues.
You should expect mixed results with various headsets out there. I’ve seen more than a few racers crash their quads then scream about their video locking up. On my end, speaking for the DJI Goggles, again, the video stream to my Mavic Pro is consistently the best video streaming I’ve ever had from the Mavic.
Related reading: DJI FPV Goggles V2.0
Traditional RC connectivity, and new WiFi connectivity efforts are designed to accept interference, and that they do, often. DJI’s Ocusync is a different beast. I know, legally, it has to accept interference, but I’ve literally been in a spot where the mobile device display had long ago froze up, the remote was throwing warnings of interference, but the HD video to the Goggles was perfect. I can’t explain it, I don’t know the tech on the inside, but certainly some good and some bad out there.
We met up with Epson and the Moverio team at InterDrone 2018 to talk about the new BT-35E AR glasses:
DJI Goggles Racing Edition
We talked about how the DJI Goggles might be too slow for your racing needs, well, DJI changed that with the new Racing Edition headset. The DJI Goggles RE have a new paint job on the outside, then on the inside they pack better radios, new camera and antenna for your drone, and rock 50 ms latency, which is much faster than the 110 ms of the original. Check out the DJI Goggles RE announcement for more details.
A fun idea: DJI Osmo Pocket
We attached the Osmo Pocket to a drone, and it was good. We began seeing video disruptions at a little over 100 feet, but the Osmo Pocket is a 3-axis stabilized camera that produces video of quality somewhere between the Mavic Air and Mavic Pro. The live video stream goes to your phone, through the DJI Mimo app, but it’s early days, we’ll see if third party support is in the pipeline. Not too bad for $299.
Preference is the name of the game. I could tell you that one of these tools is better than another – actually, I sort of did, but that’s not the point – what it really boils down to, what do you want? Laws and your type of flight may help make this decision, but some of you like using a mobile device, others can’t be bothered to look down.
I hope that I’ve given you enough info above that you can make an informed decision moving forward. We will be exploring some of the best options to be found in each of these categories as soon as we can. For now, know that there are some fun options.
Drones and goggles highlighted in this article:
Bonus for race fans: Eachine LCD5802D
May I speak frankly? Good, thank you. I had had this diversity receiver, 7-inch FPV monitor in my Amazon cart for quite some time, and only just purchased the Eachine LCD5802D this past month. The monitor pulls triple duty, or more, depending on your needs. As an FPV monitor, the diversity receivers pull double duty to ensure the best video feed possible.
As a DVR, whatever you see on the screen can be saved to microSD card, photos or video at up to 800×480 resolution, depending on your camera source – my current camera is 720×480, so that is the resolution of my saved files. The AV out means you can connect your FPV goggles to the tablet as well, enabling that VR headset racing experience. The AV input means you can use this unit as a screen for your other video receivers as well.
Full-size image capture:
Perhaps the best feature is the built-in battery. Not all equipment of this sort is self powered. As far as all-encompassing equipment goes, I’ve not found anything comparable near this price point. There are plenty of machines that can outperform this Eachines monitor in most regards, but they all cost double or more the price.
I’ve tested with several drones, and the supported 40 channels in the 5.8 GHz range does not pickup the video feed from the smaller DJI drones or the GDU O2. It does find the Hubsan H502S Desire. We’ll update if we find any popular off-the-shelf drones that work with this monitor, but for now, it is extremely likely that your racing drone will work.
Check out the Eachine LCD5802D for $140 on Amazon today. (Usually $126, watch for sales.) When the Eachine monitor is out of stock, check out this Flysight monitor for $149 instead.
That’s it for today, we hope you get the chance to try out the FPV experience with your drone, it’s challenging and a ton of fun.
Frequently Asked Questions
Do I need goggles to fly my drone?
No, you do not need googles, nor do you need a video screen at all, to fly your drone. However, it is much more fun and functional to have a live-view display as part of your operations. Being able to see what your drone is seeing is great for accuracy and safety, if nothing else. For approved commercial operators, a live view display is critical for missions where the drone is beyond the visual line of sight.
Can I use goggles and a display at the same time?
For your analog video signal, like on most racing drones, you can have as many receivers as you’d like. For digital video signals, each drone will be different. Your DJI drone with Ocusync can connect to the remote with your phone attached, and to a set of DJI Goggles simultaneously. These digital connections are both hardware and software dependent, so your options will be limited, but the video quality is usually far superior.
